MCCB Manufacturers in Chakan – Shree Laxmi Enterprises
Shree Laxmi Enterprises is the leading MCCB manufacturers in Chakan. Since we have been built using good quality materials and careful engineering, we provide better performance and longevity even in tough environments.
We have different molded case circuit breaker with different voltage and current ratings to meet different requirements and you can buy the best according to your requirement immediately. From basic protection to sophisticated features such that
We are MCCB suppliers, dealers, distributors, traders and wholesalers in Chakan to provide fault-free and reliable protection, safeguarding your electrical systems and our safety and security. Invest in the assurance of superior electrical protection.
How we are manufacturing of MCCB?
As MCCB manufacturers, there are some elementary processes and skills that characterize our business. Below is an overview of how we provide such essential electrical protection products to the market. Our quality control department ensures to meet industrial requirements.
Design and engineering we possess an efficient team of electric engineers who design and develop MCCBs to superior industry standards e.g., IEC, UL, etc. Our new plants boast high-precision machinery for the manufacture of molded case circuit breaker components.
Automatic and semi-automatic assembly lines are employed to ensure quality consistency and efficiency. We follow strict manufacturing process in an effort to achieve precise tolerances as well as normal operation.
Types of MCCB:
Being as MCCB suppliers and dealers in Pune, basically pertains to our tripping characteristics, just like Miniature Circuit Breakers. These types determine how rapidly we will trip for various overcurrent situations. Some of the types are following.
-
Type B:
This trip at 3 to 5 times the rated current. We are applied in resistive loads in commercial and industrial applications. We are for lighting and general-purpose circuits.
-
Type C:
This trip between 5 and 10 times the rated current. We are applied to inductive loads, including small motors and fluorescent lighting. Found in commercial and industrial power distribution systems.
-
Type D:
We trip at 10 to 20 times rated current. We are made for high inrush current uses, such as large motors and transformers. Applied in heavy industrial applications.
-
Type K:
We trip at 8 to 12 times rated current. We are effective in protecting motor circuits. We are applied where there are high inrush currents, and industrial power systems.
-
Type Z:
This trip at 2 to 3 times the rated current. We are highly sensitive, and protect sensitive electronic equipment. We are applied to protect semiconductor devices and other sensitive loads.
Technical Specification of MCCB:
We have added below a technical sheet of MCCB in Chakan that provides more technical information such as:
| Specification | Description | Typical Values/Ranges |
|---|---|---|
| Rated Current In | The maximum continuous current the MCCB can carry without tripping. | Ranges from 15A to 3200A or more. |
| Rated Voltage Ue | The voltage at which the MCCB is designed to operate. | Typically, 415V AC, 690V AC, or DC voltages. |
| Number of Poles | The number of conductors the MCCB can switch. | 1, 2, 3, or 4 poles. |
| Breaking Capacity Icu/Ics | The maximum short-circuits current the MCCB can interrupt. Icu is the ultimate breaking capacity, and Ics is the service breaking capacity. | Ranges from 10kA to 200kA or higher. |
| Trip Unit Type | The mechanism that triggers the MCCB to trip. | Thermal-magnetic, electronic microprocessor-based. |
| Trip Characteristics | The time-current characteristics of the trip unit, defining how quickly the MCCB trips under different overload and short-circuit conditions. | Vary, including instantaneous, short-time, and long-time delay. |
| Adjustable Trip Settings | Settings that allow adjustment of overload and short-circuit trip thresholds. | Varies depending on the trip unit type. |
| Standards Compliance | Standards to which the MCCB complies. | IEC 60947-2, UL 489, etc. |
| Operating Temperature | The range of ambient temperatures in which the MCCB can operate. | Typically -25°C to +70°C. |
| IP Rating | Ingress Protection rating, indicating the level of protection against dust and water. | Varies, such as IP20 or higher. |
| Terminal Type | The type of terminals used for connecting conductors. | Screw terminals, busbar connections, etc. |
| Accessories | Optional accessories, such as auxiliary contacts, shunt trips, and undervoltage releases. | Varies depending on the manufacturer. |
| Frequency | The frequency of the AC power the MCCB is designed for. | 50/60 Hz. |
| Impulse withstand voltage Uimp | The peak value of an impulse voltage that the equipment can withstand without failure. | Typically, 8kV. |
Features and Benefits of MCCB:
Serve as a MCCB distributors and traders in Chakan, is an essential protective device in electrical systems. So, following are the benefits of it.
-
Higher Protection:
We act very quickly when we sense overcurrent’s and de-energize the circuit to prevent damage due to excessive heat or flow of current. We offer protection against heat in instances of overloads and magnetic in the event of short circuits.
-
Reliability:
We are made of solid material and accurate mechanisms, which guarantee that we work continuously during our life expectancy. Such reliability lowers surprise downtime and delivers smooth operation of the electrical circuit.
-
Adjustability:
Trip setting adjustability offers the user a flexibility of choice of setting the reliability of that depending on the requirements of an individual load.
-
Compactness and Flexibility:
We are also made to be compact and hence extremely competent for use where space is limited. In industries' power distribution, office wiring, and in many other applications, we offer multifunctional protection.
-
Ease of Installation and Maintenance:
We are designed with the intention to be simple to install in an attempt to compensate for the installation time and labor cost. We do not need little or no maintenance schedule and thus are cost-effective in the long run.
Applications of MCCB
Serve as MCCB wholesalers in Chakan are general-purpose electrical protection devices and can be utilized in a wide variety of applications. Some of the applications as follow.
-
Industrial Applications:
We are an important part of industry for the protection of heavy machines, large motor loads, and complex electrical distribution systems. We switch off high fault currents and offer adjustable trip settings, which are important in industrial applications.
-
Commercial Buildings:
We protect electric circuits in office, shopping, and hospital buildings against short circuits and overloads. We are installed in main distribution boards and sub-distribution boards to protect lighting, HVAC equipment, and other essential devices.
-
Motor Protection:
We are generally used in the direction of motor protection. We shield the motors from short circuit faults and overload conditions, avoiding useless equipment failure.
-
Residential Electrical Panels:
While we are employed most commonly in standard residential wiring, 3VA molded case circuit breakers are employed in residential use where higher current ratings must be utilized, or in larger homes. -
Solar Power System:
We are of great application in solar photovoltaic PV systems. We protect DC circuits against overcurrent and short circuits, particularly at the inverter output. Solar caters to the singularity of DC power.
Shree Laxmi Enterprises is the best MCCB manufacturers in Chakan, provides a variety of quality and dependable molded case circuit breakers for a range of industrial and commercial uses. Our MCCBs are for protection against overcurrent’s and short circuits, without compromising on the safety and life of electrical installations. Our products are conforming and adjustable, flexible and dependable. Quality is our utmost concern, and we incorporate up-to-date production methods and strict quality control. Contact us for more details and offers.
